KUBOTA V2203 engine

The Kubota V2203 is a vertical, water-cooled, 4-cycle diesel engine with a capacity of 39.9HP at 2800RPM. Featuring a built-in solenoid, low fan position and single side serviceability, the V2203 kubota engine offers powerful performance, exceptional reliability and a long service life to meet almost any application.

Features

Kubota’s E-TVCS indirect injection system provides high power output and torque backup in a compact package.

Half-float valve cover and coated pistons offer lower noise levels than conventional diesel engines and provide reduced transmitted vibrations from the valve area for better noise characteristics.

Kubota’s original casting technology protects the engine against heat load of high power density, providing superior endurance and reliabilty.

Renowned for its exceptional reliability and long service life.

Super glow system for shortening pre-heat time and quicker engine start-up in cold weather.

Specifications

• Type Water Cooled Vertical Diesel Engine
• Number of Cylinders 4
• Bore & Stroke 80.0mm x 92.4mm
• Total Displacement (cc) 2197
• Combustion System E-TVCS
• Intake System Naturally Aspirated
• Max Output Net Intermittent kW/rpm (hp/rpm) 34.3/2800 (46.0/2800)
• Maximum Output Continuous kW/rpm (hp/rpm) 29.8/2800 (39.9/2800)
• Continuous Output Generator Spec kW/rpm(hp/rpm) 17.1/1500 (32.0/1500)
• Starting System Electric Start
• Housing Options SAE #4 – 7 1/2″ Housing/Flywheel or Standard Kubota Flywheel /Housing
• Options Full Power Pack Options (KIKS
