Cummins QSB 6.7 Diesel Engine

Features & Benefits

The advanced features of the QSB6.7 provide many benefits for your farming operation:

• High Pressure Common Rail Fuel System - Delivers high injection pressure (1600 bar) for improved performance and fuel efficiency at every rpm
• In-Cylinder Combustion Technology - Meets emissions standards without external components; is compatible with high-sulfur fuels for worldwide use
• Rear Gear Train - Significantly lowers noise output to meet worldwide noise emission standards
• Wastegated Turbocharger - Designed by Cummins Turbo Technology. Wastegated for better low-speed performance and high-speed boost
• Dual Stage Fuel Filter - Provides a balanced level of particle separation to maximize fuel filter life and protect vital fuel system components
• Parent Bore Cylinder Block - Designed for reduced noise and increased durability
• Directed Piston Cooling - Lower piston temperatures lead to longer life
• Wider Camshaft Lobes and Larger Tappet Wear Surface - Enhance durability and reliability

Specification:

• Engine Type In-Line, 6-Cylinder
• Displacement 6.7 L* (408 cu in)
• Advertised Horsepower 133-275 hp (99-205 kW)
• Peak Torque 730 lb-ft (990 N•m)
• Aspiration Turbocharged and Charge Air Cooled
• Oil System Capacity 15-25.3 U.S. qt (14.2-23.9 L*)
• Coolant Capacity 10.6 U.S. qt (10 L*)
• Length 41.7 in (1,059 mm)
• Width 28.6 in (725 mm)
• Height 37.8 in (960 mm)
• Wet Weight 1,047 lb (475 kg)
• *L=Liters/Litres
