Vetus M3.29 27hp Marine Diesel Engine
$3,200.00
Sell New Vetus M3.29 27hp Marine Diesel Engine
Vetus M3.29 27hp Marine Diesel Engine
The new Vetus Mitsubishi M3.29 is a superbly quiet, compact and reliable 3 cylinder marine diesel inboard engine. The model shown here is the inter-cooled version with pre-fitted ZF12M gearbox with a 2.14:1 ratio - ideal for small sailboats.
Simple to install - and easy to maintain, with all service items grouped on one side. The M3.29 ships with an attractive, waterproof key-switch panel (2m extendable hard-wired loom) with warning lights for low oil pressure, high water and exhaust temperature.
Specifications:
- Model : M3.29
- Stroke : 70 mm
- Bore : 76 mm
- Capacity : 952cm3
- Number of Cylinders : 3
- Compression Ratio : 22:1
- Firing Order : 1-3-2
- Alternator : 12 v - 75 A
- Max Output at Flywheel/Propshaft : 20 kW (27.2Hp) — 19.3kW (26.2Hp)
- Maximum RPM : 3600
- Torque at Max RPM : 53.1 Nm
- Fuel Consumption : 270 g/kW.h
- Gearbox & Ratio : ZF12M 2.14:1
- Dry Weight (inc Gearbox) : 123 kg
- Fuel pump lift height : 1.5 m/5 ft
- Calorifier Connection : Optional kit
- Warning Lights/Audible Alarms : oil Pressure, Water Temperature (Raw & Fresh), Charge Current
- Cooling System : Indirect Sea-Water cooling
