Perkins 403D-15 Diesel Engine
$2,100.00
Sell New Perkins 403D-15 Diesel Engine
Perkins 403D-15 Diesel Engine
The Perkins 400 Series is an extensive family of engines in the 0.5-2.2 litre range. The 3 cylinder 403-15 model is the mid-range 400 Series engine, combining performance, low operating costs and a compact package. From a packaging point of view, the 403-15 is the ideal engine for small industrial applications. Its simple, robust mechanical fuel system makes it easy to install and maintain.
Specification:
POWER RATING
| Maximum Power | 25.1 kW |
| Maximum Torque | 96 Nm @ 1800 rpm |
| Rated Speed | 2200-3000 rpm |
| Minimum Power | 20.7 kW |
EMISSION STANDARDS
| Emissions | EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII |
GENERAL
| Number of Cylinders | 3 inline |
| Cycle | 4 stroke |
| Bore | 84 mm |
| Stroke | 90 mm |
| Displacement | 1.5 l |
| Compression Ratio | 22.5:1 |
| Aspiration | Naturally aspirated |
| Combustion System | Indirect injection |
| Rotation from Flywheel End | Anti-clockwise |
| Aftertreatment | - |
| Cooling System | Liquid |
ENGINE DIMENSIONS*
| Length | 572 mm |
| Width | 453 mm |
| Height | 643 mm |
| Dry Weight | 149 kg |
Perkins 403D-15
